Remote Condenser

Home

Procedure

Installation of the remote condenser will require proper refrigeration line routing, a separate individual electrical service for the remote condenser and low voltage signal wiring between the remote condenser and the Viper unit. Also required will be the use of the calculation formula and chart found in the installation manual to determine the proper refrigeration charge for the system. The charge is based on the Rise, Drop and Run lengths of the line set.

Note: Click to view the Viper remote installation instruction manual 629097916INS for complete details.
